V 1500 P/U 4WD V8-350 5.7L (1987)

Page 1
background image

Cruise Control Switch: Testing and Inspection
Release Switch Test

Fig. 16 Release switch diagnostic chart. Custom Cruise III

    Refer to Fig. 16 to check cruise release switch and related wiring.
