Yukon V8-393 6.5L DSL Turbo (1993)
![background image](/gmc/yukon/v8-393_6.5l_dsl_turbo/Page-1346003.png)
Details Of Stakes In Front Head For Clutch Coil
-
Stake size should be only one-half the area of the punch tip and be only approximately 0.28-0.35mm (0.010-0.015") deep.
6. Install rotor and bearing assembly and the clutch plate and hub assembly.
