Accord L4-2.4L (2005)
Wheels: Testing and Inspection
Wheel Runout Inspection
Front and Rear Wheel Axial Runout
1. Raise the vehicle, and support it with safety stands in the proper locations.
2. Check for a bent or deformed wheel.
3. Set up the dial gauge as shown, and measure the axial runout by turning the wheel.
Front and rear wheel axial runout:
Standard:
Steel wheel: 0 - 1.0 mm (0 - 0.04 inch)
Aluminum wheel: 0 - 0.7 mm (0 - 0.03 inch)
Service limit: 2.0 mm (0.08 inch)
Steel wheel
Aluminum wheel
4. Reset the dial gauge to the position shown, and measure the radial runout.
Front and rear wheel radial runout:
Standard:
Steel wheel: 0 - 1.0 mm (0 - 0.04 inch)
Aluminum wheel: 0 - 0.7 mm (0 - 0.03 inch)
Service limit: 1.5 mm (0.06 inch)
Front and Rear Wheel Radial Runout
