Accord DX Sedan L4-2254cc 2.3L SOHC MFI (2001)
Heated Glass Element Relay: Testing and Inspection
Check for continuity between the terminals.
-
There should be continuity between the No.1 and No.3 terminals when power and ground are connected to the No.2 and No.4 terminals.
-
There should be no continuity between the No.1 and No.3 terminals when power is disconnected.
Rear Window Defogger Relay
Rear window defogger relay
