Accord LX Sedan L4-2254cc 2.3L SOHC (VTEC) MFI (1998)
Paint: Service and Repair
Soft Chipping Guard Primer Coat
Coating Procedures
NOTE: This section covers the application of the soft chipping primer to the replacement part.
1. Sanding the replacement part
WARNING: Wear goggles or safety glasses to prevent eye injury.
Sand the area to be painted with #240-#400 sand paper.
NOTE:
-
Do not oversand the edges or corners of the part.
-
Do not expose bare metal.
2. Air blowing/degreasing
WARNING:
-
Do not use high air pressure; use only an approved, 210 kPa (2.1 kgf/sq.cm, 30 psi) air nozzle.
-
Wear goggles or safety glasses to prevent eye injury.
-
Paint thinner is flammable. Store it in a safe place, and keep it away from sparks, flames or cigarettes.
Clean the surface with compressed air and wax and grease remover.
3. Masking
-
Place masking tape or paper around the surface to be painted.
-
Cover as wide an area as possible with tape or paper to keep primer from spreading.
4. Spraying chipping guard primer
-
Stir the primer thoroughly.
-
Put the primer in a beaker and weigh the needed amount of primer to be used.
-
Mix the hardener into the primer, following the manufacturer's instructions.
NOTE: Measure the primer and hardener so they are in correct ratio.
-
Add the specified thinner to the mixture of hardener and primer to attain the proper viscosity for spraying.
2C 68 degrees F (20 degrees C) 18 sec ± 1
-
These substances are not available in the using DuPont's 123 Vinyl Coating, or Sherwin-Williams' Vinyl Gravel Guard. Follow the
manufacturer's instructions for application.
-
Use the following materials:
-
Spies Hecker Permacron 4:1 Surfacer 4:1 (Hoechst)
-
Standox 2K 4:1 Special Filler (Herberts)
-
Once mixed with the hardener and thinner, the primer must be used within the times shown.
WARNING:
-
Most paints contain substances that are harmful if inhaled or swallowed. Read the paint label before opening the container. Spray
paint only in a well ventilated area.
