Civic L4-1.3L Hybrid (2008)
Body Emblem: Service and Repair
Emblem/Sticker Replacement
NOTE: When removing the emblems/sticker, take care not to scratch the body.
1. To remove the front "H" emblem, remove the front grille.
2. Clean the body surface with a sponge dampened in isopropyl alcohol. After cleaning, keep oil, grease, and water from getting on the surface.
3. Apply the emblem/sticker where shown. When installing the PZEV sticker on the inside surface of the left rear door quarter glass, align the sticker
with the edge of the glass mark as shown, then press the sticker into place, and remove the application tape.
4. After installing the front "H" emblem, reinstall the front grille.
