Civic L4-1.3L Hybrid (2008)
Trim Panel: Service and Repair
Trim Removal/Installation - Pillar Areas
Trim Removal/Installation - Pillar Areas
Special Tools Required
KTC trim tool set SOJATP2014 *
* Available through the Honda Tool and Equipment Program.
A-Pillar Trim
SRS components are located in this area. Review the SRS component locations and the precautions and procedures before doing repairs or service.
NOTE:
-
Follow the A-pillar trim installation procedure carefully; improper installation could cause the side curtain airbag to deploy improperly and
possibly cause injury.
-
Put on gloves to protect your hands.
-
Use the appropriate tool from the KTC trim tool set to avoid damage when prying components.
-
Take care not to scratch the trim and the panels.
-
The upper clip in the A-pillar trim (A) consists of a grommet (B) and a pin (C). The grommet expanded with the pin secures it to the body panel
(D). The projections (E) on the pin is broken during removal, so the clip must be replaced with a new one when the trim is reinstalled.
1. Pull the front door opening seal away from the A-pillar as needed.
2. Hit the upper clip in the A-pillar trim (A) with a rubber mallet. The clip is under the "SIDE CURTAIN AIRBAG" mark (B). Hitting the clip
breaks the projections (C) on the pin (D) and pushes it into the grommet (E) against the body (F). The grommet becomes narrower.
NOTE: The clip must be replaced with a new one when the A-pillar trim is reinstalled.
3. Pull the front of the A-pillar trim (A) back by hand to remove the upper clip (B) from the body (C).
