Civic L4-1.8L (2006)
9. Pour Honda Long Life Antifreeze/Coolant Type 2 into the radiator up to the base of the filler neck.
NOTE:
^
Always use Honda Long Life Antifreeze/Coolant Type 2 (P/N OL999-9001). Using a non-Honda coolant can result in corrosion, causing the
cooling system to malfunction or fail.
^
Honda Long Life Antifreeze/Coolant Type 2 is a mixture of 50 % antifreeze and 50 % water. Do not add water.
10. Loosely install the radiator cap.
11. Start the engine, and let it run until it warms up (the radiator fan comes on at least twice).
12. If the maintenance minder required to replace the engine coolant, reset the maintenance minder, and this procedure is complete. If the maintenance
minder did not require to replace the engine coolant, go to step 13.
13. Connect the HDS to the data link connector (DLC).
14. Turn the ignition switch ON (II).
15. Select BODY ELECTRICAL with the HDS.
16. Select ADJUSTMENT in the GAUGES MENU with the HDS.
17. Select RESET in the MAINTENANCE MINDER with the HDS.
18. Select MAINTENANCE SUB ITEM 5 RESET with the HDS.
19. Turn off the engine. Check the level in the radiator, and add Honda Long Life Antifreeze/Coolant Type 2, if needed.
20. Put the radiator cap on tightly, then run the engine again, and check for leaks.
21. Clean up any spilled engine coolant.
