Civic L4-1.8L CNG (2008)
Air Bag Deactivation Indicator: Testing and Inspection
Passenger's Airbag Cutoff Indicator Illumination Bulb Test
1. Remove the center panel:
-
With navigation
-
Without navigation
2. Remove the screws (A) and the passenger's airbag cutoff indicator (B) from center panel.
3. Check for continuity between the No. 2 and No. 3 terminals of the indicator. If there is no continuity, replace the bulb.
4. Reinstall the parts in the reverse order of removal.
