Civic Hatchback L4-1.6L SOHC (16 Valve) (1996)
Windshield Washer Hose: Service and Repair
Washer Tube Replacement
NOTE:
-
To remove the windshield washer tube, remove the left inner fender.
-
To remove the rear window washer tube (3D), remove the following parts from the left side of the vehicle.
-
Inner fender
-
Kick panel and side trim
-
Rear seat-back and rear seat cushion
-
Spare tire lid
-
Rear center shelf and rear side shelf
-
Rear trim panel and side trim panel
-
Quarter trim panel
-
Rear roof trim
