Civic HX Coupe L4-1590cc 1.6L SOHC (VTEC-E) MFI (1997)
_mfi/Page-1351001.png)
Case: Service and Repair
Transmission Housing Replacement
REMOVAL
NOTE: Place the clutch housing on two pieces of wood thick enough to keep the mainshaft from hitting the workbench.
1. Remove the back-up light switch.
2. Remove transmission hanger.
3. remove the setting screws, washers, springs, and steel balls.
4. Loosen the transmission housing attaching bolts in a crisscross pattern in several steps, then remove them.
5. Remove the 32 mm sealing bolt.
