CR-V 4WD L4-2.4L (2004)
Scuff Plate: Service and Repair
Trim Removal/Installation - Door Area
Special Tools Required
KTC trim tool set SOJATP2014
NOTE:
-
Put on gloves to protect your hands.
-
Use the appropriate tool from the KTC trim tool set to avoid damage when prying components.
-
Take care not to bend or scratch the trim and panels.
1. Remove the trim as shown:
2. Install the trim in the reverse order of removal, and note these items:
-
Replace any damaged clips.
-
Push the clips into place securely.
-
Apply liquid thread lock to the front seat belt anchor bolts before installation.
-
Before installing the anchor bolts, make sure there are no twists or kinks in the seat belt.
