background image

Alignment: Specifications

Alignment

Caster angle:

2WD ............................................................................................................................................................................................................  1°59' ± 1°
4WD ............................................................................................................................................................................................................  1°53' ± 1°

Camber angle:

Front:

2WD ....................................................................................................................................................................................................  -0°40' ± 1°
4WD ....................................................................................................................................................................................................  -0°30' ± 1°

Rear:

2WD ...................................................................................................................................................................................................  -0°40' ± 45'
4WD ...................................................................................................................................................................................................  -0°30' ± 45'

Front toe-in ................................................................................................................................................................................  0 ± 2 mm (0 ± 1/16 inch)
Rear toe-in:

2WD ...............................................................................................................................................................................  2 ± 2 mm (1/16 ± 1/16 inch)
4WD ....................................................................................................................................................................................  0 ± 2 mm (0 ± 1/16 inch)
