Pilot 4WD V6-3.5L (2008)
Rear Door Exterior Handle: Service and Repair
Rear Door Outer Handle Replacement
NOTE: Put on gloves to protect your hands.
1. Remove these items:
-
Door panel
-
Plastic cover, as necessary
2. Raise the glass fully.
3. Release the hooks (A), then remove the rod protector (B) by detaching the clip (C).
4. Remove the screws securing the latch (A), then lower the latch.
5. Remove the maintenance seal (A), then disconnect the outer handle rod (B) from the joint bushing (C).
NOTE: Check for damaged or stress-whitened joint bushing, and replace if necessary.
