Workshop Manuals Factory service & repair Honda
Honda Prelude L4-2056cc DOHC (1990)11 · Heating and Air Conditioning
11 · Heating & A/C

Refrigerant Oil: Specifications

Make
Honda
Model
Prelude
Engine
L4-2056cc DOHC
Year
1990
Section
Refrigerant Oil › Specifications
Heating and Air ConditioningSpecifications
background image

Refrigerant Oil: Specifications



Condenser

10 cc







Evaporator

30 cc







Line or hose

10 cc







Receiver

10 cc







Compressor: Matushita 130 cc

For replacement, subtract the volume of oil drained from



the removed compressor from 130cc or 120cc and drain the



calculated volume of oil from the new compressor.



130cc-volume of removed compressor=draining volume



(Matushita)









Compressor Sanden

120 cc

For replacement, subtract the volume of oil drained from



the removed compressor from 130cc or 120cc and drain the



calculated volume of oil from the new compressor. 120cc-



volume of removed compressor=draining volume (sanden)
