9. Remove the timing belt middle cover and the lower cover.

10. Loosen the adjust bolt, then remove the timing belt.
11. Install in the reverse order of removal.

NOTE:
-

Install the timing belt with the No. 1 piston at Top Dead Center (TDC) on the compression stroke.
