Prelude L4-2157cc 2.2L DOHC (VTEC) MFI (2001)
_mfi/Page-1503001.png)
Alternator: Specifications
Measurement
Standard
Service Limit
Output at hot
100 A at 13.5 V
---
Coil Resistance
2.8 - 3.0 K ohms at 68 deg F
---
Slip Ring O.D
14.4 mm
14.0 mm
Brush Length
10.5 mm
1.5 mm
Brush Spring Tension 2.9 - 3.5 N
---
