Prelude L4-2157cc 2.2L DOHC (VTEC) MFI (2001)
_mfi/Page-1648004.png)
NOTE:
-
The damper mounting bolts should be tightened with the damper under vehicle load.
-
Do not interchange the right and left dampers.
3. Tighten the damper mounting nuts.
4. Connect the upper arm and knuckle, then tighten the castle nut.
5. Raise the rear suspension with a floor jack until the weight of the vehicle is on the damper.
6. Tighten the damper mounting bolt.
7. Install the trunk side trim.
8. Check the rear wheel alignment and adjust if necessary.
NOTE: For vehicles equipped with ATTS, make sure the front wheels are in the straight ahead position (mechanical neutral) after the wheel
