Prelude L4-2157cc 2.2L DOHC (VTEC) MFI (2001)

Page 1
background image

Clutch Disc: Specifications



Disc Thickness

Standard

8.3 to 9.0 mm









Service Limit

6.0 mm











Rivet Depth

Standard

1.2 to 1.7 mm

From lining surface to rivets.











Service Limit

0.2 mm
