Prelude L4-2157cc 2.2L DOHC (VTEC) MFI (2001)
![background image](/honda/prelude/l4-2157cc_2.2l_dohc_(vtec)_mfi/Page-1257005.png)
4. Seat the external circlip in the groove of the intermediate shaft.
5. Press the outer seal into the bearing support using the special tools and a press.
CAUTION: Do not damage the lip on outer seal during installation.
NOTE: Press the seal flush with the bearing support.
6. Install the new set ring in the intermediate shaft groove.
INSTALLATION
1. Insert the intermediate shaft assembly into the differential.
CAUTION: Hold the intermediate shaft horizontal to prevent damage to the differential oil seal.
2. Install the flange bolt and dowel bolts, then tighten them.
