Ridgeline V6-3.5L (2006)
Axle Shaft Assembly: Service and Repair
Rear Driveshaft Disassembly
Rear Driveshaft Disassembly
Special Tools Required
Threaded adapter, 24 x 1.5 mm 07XAC-001020A
Inboard Joint Side
1. Remove the boot bands. Be careful not to damage the boot.
^
If the boot band is a locking tab type (A), pry up the locking tab (B) with a screwdriver, and lift up the end of the band.
^
If the boot band is a double loop type (C), lift up the band end (D), and push it into the clip (E).
2. Remove the circlip (A).
