S2000 L4-2.2L (2004)
10. Measure the clutch disc thickness. If the thickness is less than the service limit, replace the clutch disc.
11. Measure the rivet depth from the clutch disc lining surface (A) to the rivets (B), on both sides. If the rivet depth is less than the service limit,
replace the clutch disc.
Flywheel Inspection
1. Inspect the ring gear teeth for wear and damage.
2. Inspect the clutch disc mating surface on the flywheel for wear, cracks, and burning.
3. Measure the flywheel (A) runout using a dial indicator (B) through at least two full turns with the engine installed. Push against the flywheel each
time you turn it to take up the crankshaft thrust washer clearance. If the runout is more than the service limit, replace the flywheel, and recheck the
runout. Resurfacing the flywheel is not recommended.
