H3 L5-3.7L (2007)
Hydraulic Brake Booster: Service and Repair
Brake Master Cylinder with Power Brake Booster and Chassis Control Module Replacement
Brake Master Cylinder with Power Brake Booster and Chassis Control Module Replacement
Removal Procedure
Important:
*
In the following service procedure, plug the brake pipes to avoid dirt or any type of contaminates to enter the brake system.
*
Depress the brake pedal 20 times to release accumulator pressure.
Disconnect the rear and left front brake pipes from the brake master cylinder.
2. Disconnect the right front brake pipe from the brake master cylinder.
3. Disconnect the electrical connectors at the brake pressure modulator valve (BPMV).
