H3 L5-3.7L (2007)
Air Bag Control Module: All Technical Service Bulletins
Restraints - Air Bag Lamp ON/DTC B0092 Set
Bulletin No.: 07-09-41-005
Date: July 10, 2007
TECHNICAL
Subject:
Airbag Light On, Passenger Airbag Status Indicator Reads Off, DTC B0092 Set (Diagnose and Replace SDM, if Necessary)
Models:
2007 Chevrolet TrailBlazer
2007 GMC Envoy
2007 HUMMER H3
without Roof Side Inflatable Restraint (RPO ASF)
Condition
Some customers may comment that the airbag light is illuminated and the passenger airbag status indicator reads off even though a occupant is in the
seat.
Upon investigation, the technician may find communication error DTC B0092 set in the sensing and diagnostic module (SDM).
Correction
Using the Tech 2(R), request module ID information to determine the part number of the SDM. If the SDM part number is 25833651
(Envoy/TrailBlazer) or 25833286 (H3), replace the SDM before proceeding with DTC B0092 diagnosis. If the part number of the SDM is other than
those listed above, follow diagnostic instructions published in SI.
Parts Information
Warranty Information
