Accent GS Coupe L4-1495cc 1.5L SOHC MFI (1999)

Page 1
background image

Brake Pedal Assy: Adjustments

BRAKE PEDAL INSPECTION AND ADJUSTMENT

1. The clearance between the stop lamp switch outer case and the pedal arm.

2. Brake pedal free play.

3. Start the engine, apply the brake pedal with approximately 50 kg (110 lbs.) of force, and measure the clearance between the brake pedal and the

floor board.
