Accent GS Coupe L4-1495cc 1.5L SOHC MFI (1999)
8. Loosen the tensioner mounting bolts 1 and 2 in that order as shown. This will apply spring tension to the timing belt only. Check the belt to ensure
that it is not out of position.
9. Tighten the tensioner tightening bolts 1 and 2 in that order. If the bolt 1 is tightened first, the tensioner will move with the belt in the direction that
the belt is tightened.
10. Give the crankshaft one turn in operating direction (clockwise) and realign crankshaft sprocket timing mark with the top dead center position.
CAUTION: Do not turn the crankshaft in a counterclockwise direction. The crankshaft should turn smoothly.
11. Loosen the tensioner attaching bolt 1 and 2 in that order.
12. Tighten the tensioner attaching bolts 2 and 1 in that order to the specified torque.
Tightening torque:
Tensioner attaching bolt: 20-27 Nm (200-270 kg.cm, 14-20 ft. lbs.)
13. Then recheck the belt tension. Verify that when the tensioner and the tension side of the timing belt are pushed in horizontally with a moderate
force [approx. 49 N (11 lbs.)], the timing belt cog end is approx. 1/2 of the tensioner mounting bolt head radius (across flats) away from the bolt
head center.
14. Install the timing belt cover.
Tightening torque:
Timing belt cover bolt: 10-12 Nm (100-120 kg.cm, 7-9 ft. lbs.)
15. Install the crankshaft pulley. In the case, make sure that the crankshaft sprocket pin fit the small hole in the pulley.
16. Install the fan belt and adjust the belt tension.
17. Install the water pump pulley
18. Install V-belt and adjust the belt tension.
