Center Mounted Brake Lamp: Service and Repair

1. Disconnect the battery negative terminal.
2. Using a screw driver, detach 2 blanking covers on both sides of the lamp.
3. Loosen the mounting screws.

4. Remove the lamp assembly from the rear package trim.
5. Disconnect the connector from main harness.
6. Installation is the reverse order of removal.
