Accent GS Coupe L4-1495cc 1.5L SOHC MFI (1999)
8. Remove the camshaft sprocket.
9. Remove the timing belt.
NOTE: If the timing belt is reused, make an arrow mark indicating the turning direction (or the front of the engine) to make sure that the belt is
reinstalled in the same direction as before.
10. Remove the crankshaft sprocket bolts. Remove the crankshaft sprocket and flange.
11. Remove the timing belt tensioner.
INSPECTION
Timing Belt
1. Check the belt for oil or dust deposits. Replace, if necessary. Small deposits should be wiped away with a dry cloth or paper. Do not clean with
solvent.
