Accent GS Coupe L4-1495cc 1.5L SOHC MFI (1999)
Intake Air Temperature Sensor: Description and Operation
INTAKE AIR TEMPERATURE (IAT) SENSOR
The Intake air temperature (IAT) sensor is located in the air cleaner. The AT sensor is a variable resistor whose resistance changes as the temperature of
the air flowing through the air intake changes.
The Engine Control Module (ECM) uses the AT sensor input to adjust fuel injector pulse width. When the temperature sensed is cold, the ECM enriches
fuel mixture by increasing injector pulse width; as the air warms, the injector pulse width time is shortened.
