Accent GS Coupe L4-1495cc 1.5L SOHC MFI (1999)
3. Remove the piston from the release cylinder using compressed air.
CAUTION:
1. Cover with rags to prevent the piston from popping out and causing injury.
2. Apply compressed air slowly to prevent the fluid from splashing in your eyes or on your skin.
INSPECTION
1. Check the release cylinder bore for rust and damage.
2. Check the clutch release cylinder for fluid leakage.
3. Check the clutch release cylinder for boots for damage.
4. Measure the release cylinder bore at three locations (bottom, middle and top) with a cylinder gauge and replace the release cylinder assembly if the
bore to piston clearance exceeds the limit.
Limit: 0.15 mm (0.006 inch)
REASSEMBLY
1. Apply specified brake fluid to the release cylinder bore and the outer surface of the piston and piston cup, and push the piston cup assembly into
the cylinder.
Use the specified fluid: Brake fluid DOT 3
2. Install the clutch hose, valve plate, spring, push rod and boot.
INSTALLATION
1. Coat the push rod surface with the specified grease.
Specified grease: MOLYWHITE TA No.2
