Accent GS Coupe L4-1495cc 1.5L SOHC MFI (1999)
Clutch Pedal Assembly: Specifications
Clutch Pedal Free Play
6 - 13 mm
Clutch Pedal To Floor Board Clearance
90 mm
(When The Clutch Is Disengaged)
Clutch Pedal Stroke Limit
145 mm
Clutch Pedal To Pedal Support Member
19 - 28 Nm
(Clutch Pedal Bracket)
Clutch Pedal Support Member
17 - 21 Nm
