Accent GSI Coupe L4-1495cc 1.5L DOHC MFI (1998)
Diagnostic Connector - Fuel Pump: Technical Service Bulletins
Fuel Pump - Check Connector Location Change
Group: FUEL SYSTEM
Number: 98-30-001
Date: JUNE, 1998
Model: 1998 ACCENT
Subject
ACCENT FUEL PUMP CHECK CONNECTOR LOCATION CHANGE
DESCRIPTION:
This bulletin describes the new fuel pump check connector location for 1998 MY Accent. Refer to the Service Tips and illustrations when checking for
proper fuel pump operation. The fuel pump check connector has been moved from the engine compartment to the interior near the fuse box.
SERVICE TIPS:
If the engine is hard to start or does not start, it may be necessary to check the operation of the fuel pump.
1.
Turn the ignition off.
2.
Apply battery (+) voltage to the fuel pump check connector to confirm that the fuel pump is operating.
Note:
The fuel pump is an in-tank type and its operation may not be audible without first removing the fuel filler cap.
3.
Pinch the hose to check (feel) for pressure.
