Accent GSI Coupe L4-1495cc 1.5L DOHC MFI (1998)
Alignment: Technical Service Bulletins
Suspension - Rear Suspension Alignment Spec. Change
Group
50 - CHASSIS
Number
97-50-006
Date
09-1997
Model
Accent 1998
Subject
REAR SUSPENSION TOE-IN ALIGNMENT CHANGE
DESCRIPTION:
The rear floor center cross member assembly and the cup flange and bolt assembly have been changed. Along with these changes, the rear wheel toe-in
alignment specification has been changed as shown.
SERVICE TIPS:
TOE ADJUSTING METHOD
1.
Adjust by turning the cam bolt.
SPECIFICATION
Standard Value: 3 (+/-2) mm
NOTE
The rear suspension mounting bolt should be turned an equal amount on both sides when adjusting.
Left wheel (Clockwise): toe-in
Right wheel (Clockwise): toe-out
