Water Pump: Specifications

TIGHTENING TORQUE

Coolant pump pulley bolts ................................................................................................................................  8 - 10 Nm (80 - 100 kgf-cm, 6 - 7 ft. lbs.)
Coolant pump bolts ...................................................................................................................................  20 - 27 Nm (200 - 270 kgf-cm, 14 - 19 ft. lbs.)

Water pump sequence

Install the water pump (B) and a new gasket with the 3 bolts.
Install the alternator brace (A) with the 2 bolts (C).
Install the 4 bolts and pump pulley.
