Santa Fe L4-2.4L (2001)
Air Door Actuator / Motor: Description and Operation
Temperature Control Actuator
TEMPERATURE CONTROL ACTUATOR
Temperature Control Actuator
1. Temperature control actuators are installed in the heater unit case. The control switches and the vent duct switch will operate actuators to regulate
the temperature and discharge air.
2. Temp switch terminal voltage check.
