Santa Fe L4-2.4L (2001)
Refrigerant Pressure Sensor / Switch: Description and Operation
TRIPLE SWITCH
The triple switch is a combination of a medium switch as well as conventional low pressure and high pressure switches. The low pressure switch will be
turned off to stop compressor operation if refrigerant pressure is low. The high pressure switch will be turned off to stop compressor operation if
refrigerant pressure is too high. The medium switch will be turned on at medium level pressure to cool the A/C system operating radiator fan and
condenser fan at high speed.
Operating Characteristic
