Santa Fe FWD V6-2.7L (2007)
Fuel Pressure Regulator: Service and Repair
FUEL PUMP
REMOVAL (INCLUDING FUEL FILTER AND FUEL PRESSURE REGULATOR)
1. Preparation
1. Remove the 2nd seat.
2. Open the carpet for fuel pump (A). SCMF16135L
3. Remove the service cover for fuel pump (A).
4. Disconnect the fuel pump connector (A).
5. Start the engine and wait until fuel in fuel line is exhausted.
6. After engine stops, turn the ignition switch off.
