Scoupe L4-1468cc 1.5L SOHC (12 VALVE) (1993)

Page 1
background image

Coolant Temperature Sensor/Switch (For Computer): Specifications



Output Voltage

 0C

4.05 V

Note: ECT Sensor side connector No.2 or ECM harness side



connector No.45











 20C

3.44 V











 40C

2.72 V











 80C

1.25 V
