Sonata V6-3.3L (2006)
Oil Filter Housing: Service and Repair
OIL FILTER ASSEMBLY
REMOVAL
1. Loosen the oil filter cap by turning it counterclockwise to drain well the oil in the oil filter.
2. Remove surge tank and intake manifold.
3. Disconnect oil pressure switch connector.
4. Drain the engine coolant.
5. Disconnect water hoses from ETC.
6. Remove water temperature control assembly.
7. Disconnect water vent hose (A).
8. Remove oil filter body cover (B).
9. Remove oil filter body. (A).
NOTE: Be careful of the knock sensor connector.
INSTALLATION
