Sonata GLS V6-2.7L (2002)
5. Evenly apply a light coat of glass primer to the windshield glass and then let it dry for 1 to 15 minutes.
NOTE
-
Do not apply body primer to the glass.
-
The primer strengthens the adhesive, so be sure to apply it evenly around the entire circumference.
Also, an application too thick will weaken the adhesive.
-
Never touch the primed surface with your hand. If you do, the adhesive may not bond to the glass properly, causing a leak after the windshield
is installed.
-
Keep water, dust, and abrasive materials away from primed surface.
6. Glue the rubber dam to the inside surface of the windshield glass around the edge as shown, to contain the sealant during installation.
7. Install the windshield glass molding.
Do not allow any gaps.
8. Apply the light coat of body primer to the original sealant remaining around the body flange. The glass should be installed 10 minutes after you
apply the primer.
9. Pack adhesive into the cartridge without air packets, to ensure continuous application. Put the cartridge in a caulking gun or sealant gun, and run a
bead of adhesive around the edge of the glass as shown.
NOTE: Apply the adhesive within 5 minutes after applying the glass primer
