Tiburon V6-2.7L (2004)
When Ignition 2 is on, the power window relay output is turned on.
When Ignition 2 is turned off the power window feed is maintained on for 30 seconds and then turned off. If the driver door or assist door is
opened during 30 sec interval the output shall be turned off immediately. If doors are open and ignition 2 is then turned on, the output shall be
turned on immediately. If doors are open and ignition 2 is then turned off, the output shall be turned off immediately.
12. Rear defog control (Rear demister control)
When the engine is running (Alternator"L"is high) a contact of the rear defog switch (momentary action) will switch the rear defog relay output on
for 20 minutes duration.
If the rear defog switch is pressed again during this time, or if the engine stops, the rear defog relay is immediately switched off.
13. Ignition key hole illumination
When the drivers door is open, the ignition key illumination is turned on.
When driver door is closed, illumination is on for 10 sec, then off.
When the assist door is open, the ignition key illumination is turned on.
When assist door is closed, illumination is on for 10 sec, then off.
The key illumination is extinguished immediately when the ignition 1 comes on.
Locking of the vehicle from the transmitter (arm state) shall extinguish ignition key Illumination.
14. Decayed room lamp (Illuminated entry with fade out)
