2. Remove the rear combination lamp.

Disconnect the combination lamp connector.

3. Loosen the rear bumper cover mounting screw from the rear wheel house.

4. Loosen the rear bumper cover mounting screw from the rear wheel house.

5. Loosen the rear bumper upper part mounting screws.
