Tiburon V6-2.7L (2004)
PROM - Programmable Read Only Memory: All Technical Service Bulletins
Engine Controls - Intermittent Hesitation While Driving
Group: ENGINE ELECTRICAL
Number: 04-36-016
Date: SEPTEMBER, 2004
Model: TIBURON(GK)
Subject
2003-2004 TIBURON(GK) 2.7L ECM REPROGRAMMING FOR INTERMITTENT HESITATION
DESCRIPTION:
Some 2003-2004 TIBURON(GK) 2.7L vehicles may experience intermittent hesitation while driving.
This bulletin provides a procedure for updating the ECM (Engine Control Module) software with new logic to improve the above condition by using the
Hi-Scan Pro.
VEHICLES AFFECTED:
^
Model : 2003-2004 TIBURON(GK) 2.7L vehicles
^
Affected vehicle production date range
^
Job 1, 2003MY September 15, 2004
^ Area : North America
ECM SPECIFICATIONS:
ECM REPROGRAMMING PROCEDURE:
CAUTIONS BEFORE REPROGRAMMING:
1.
Conduct reprogramming with the ignition key in the "ON" position.
2.
Be careful not to disconnect any cables connected to the vehicle or Hi-Scan Pro during reprogramming.
WARNING:
If reprogramming is interrupted, the manual update procedure must be used.
3.
Do not start the engine during reprogramming.
4.
Do not turn the ignition key OFF during reprogramming.
5.
When the reprogramming is completed, turn OFF the ignition key for 20 seconds before starting the engine.
