Hyundai Workshop Service and Repair Manuals > Tiburon V6-2.7L (2004) > Starting and Charging | Power and Ground Distribution | Relays and Modules - Power and Ground Distribution | Relay Box | Component Information | Application and ID | Passenger Compartment Fuse/Relay Box | Page 6270

Relay Box|Testing and Inspection > < Passenger Compartment Fuse/Relay Box|Page 6269

Page 2

background image

E/R Box Circuit Details

Starting and Charging
Power and Ground Distribution
Relays and Modules - Power and Ground Distribution / Relay Box / Component Information
Application and ID / Passenger Compartment Fuse/Relay Box
Page 6270

Relay Box|Testing and Inspection > < Passenger Compartment Fuse/Relay Box|Page 6269
