Tiburon V6-2.7L (2004)
7.
Reinstall the tire and wheel assembly and re-compensate the alignment equipment. Rotate the EZ Cam XR bolt to obtain desired camber reading.
TIP:
Prior to final alignment, the spindle camber angle may be adjusted close to the desired value with a magnetic base adjustable camber gauge as
shown. The magnetic camber gauge may be purchased from Specialty Products Company, P/N 8113.
8.
Torque bolts as shown above.
NOTE:
Always check for proper clearance between suspension components and other components of the vehicle.
9.
Complete alignment and road test vehicle.
NOTE:
Additional information regarding the EZ Cam(TM) XR camber bolt application and installation information may be found at web site:
mwww.specprod.com or call toll free 1-800-525-6505.
WARRANTY INFORMATION
