Tiburon V6-2.7L (2004)
11. Install the suction pipe and O-ring.
INSTALLATION
1. After installing the oil pump to the oil pump bracket, install the "V" belt and tighten the bolt adjusting tension to the specified torque.
Oil pump adjusting bolt:..............................3.5 - 5.0 Nm (350 - 500 kg cm, 25.8 - 37 ft. lbs.)
2. Install the suction hose.
CAUTION: Install the pressure hose to the oil pump, facing the painted part on the hose toward the oil pump.
3. Install the pressure hose to the oil pump.
NOTE: Install the pressure hose being careful so that it does not twist and come in contact with other components.
4. Add power steering fluid (PSF-3).
5. Air bleed the system.
6. Check the oil pump pressure.
