Tiburon V6-2.7L (2004)
2. Tailgate trims.
3. Rear wiper and wiper motor.
2. Remove the tailgate glass in the same manner as the windshield glass.
INSTALLATION
1. Using a cutter knife or the special tool (09861-31200), scrape the old sealant smoothly to a thickness of about 2 mm (0.08 in.) on the bonding
surface around the entire tailgate glass.
CAUTION: Be careful not to remove more adhesive than necessary, and also not to damage the paintwork on the body surface with the
knife. If the paintwork is damaged, repair the damaged area with touch-up-paint.
2. Clean the body bonding surface with a sponge dampened in alcohol or wax and grease remover.
3. Center a new tailgate glass in the opening. Mark the location by marking lines across the glass and body with a grease pencil at the four points as
shown.
4. Install the tailgate glass molding without any gaps.
5. Apply a light coat of glass primer around the tailgate glass.
NOTE:
1. Never touch the surface applied primer with your hands.
If you do, the adhesive may not bond to the glass properly, causing a leak after the tailgate glass has been installed.
2. Do not apply body primer to the glass.
3. Keep water, dust, and abrasive materials away from the surface applied primer.
