Front Door Window Regulator|Service and Repair|Page 8153 > < Front Door Window Regulator|Service and Repair
Page 2
background image

5. Remove the door grip handle mounting bracket, speaker and door trim seal.

6. Remove the door tooling hole cover.

7. Remove the door glass stopper catch.

Tightening torque: 3.9-5.9 N.m (0.4-0.6 kgf.m, 2.9-4.3 lbf.ft)

8. Remove the door delta chassis.
