Tucson AWD L4-2.0L (2007)
5. Temporarily loosen tensioner pulley (A) by center bolt.
6. Timing belt tension adjusting.
1) Rotate crankshaft in regular direction (clockwise view from front) through angle equivalent to two teeth (18°) of camshaft sprocket (A).
2) Give tension to timing belt rotating tensioner in arrow direction tool and set timing belt not to give slack to tension side.
3) Tightening tensioner bolt.
Tightening torque
Tensioner bolt 43 - 55 Nm (430 - 550 kgf-cm, 32 - 40 ft. lbs.)
