1) Temporarily install the camshaft sprocket bolt.
2) Hold the hexagonal head wrench (A) portion of the camshaft with a wrench (B), and tighten the camshaft sprocket (C) bolt.
Tightening torque
Camshaft sprocket bolt 100 - 120 Nm (1000 - 1200 kgf-cm, 74 - 89 ft. lbs.)
2. Install cylinder head cover.
1) Install cylinder head cover (A) and 12 bolts (B).
2) Install the PCV hose (A) and breather hose (B).
